Creation and design of façades in 2D with WebGL technologies, which also enable the designs to be viewed in 3D and Augmented Reality. The designs can be exported to BIM (IFC) and CAD (DXF). Furthermore, the exploded view of the products designed is exported to Microsoft Excel and infographs can be created with renderings of the designs.
The objective of the FACADE CLOUDFIG asset is aimed at providing companies with a visual and attractive design tool for façade projects. Using a folded plan of the façade and the company catalogue, the software enables the exploded view of the ventilated panels to be designed and the necessary structure calculated for their installation, automatically obtaining the document of the system designed, which includes the list of materials, CAD and BIM designs, selected options, attractive images of the result, technical documents for the assembly and product certificates.
It can be accessed from anywhere in the world, allowing for collaboration between the designer, distributor and manufacturer. Unlike software that requires installation, this platform can be used by the technical department and any distributor, sales rep or architect. The guiding process enables errors in the preparation of the projects to be reduced, facilitating the client’s understanding.
